G121XN01 V0 is one of the best-selling products we sell, widely used in industrial, commercial, medical, and other industries, and well received by customers around the world. Our products are uniquely designed with high brightness, high contrast ratio, wide viewing angle, wide temperature operation, longer lamp life, and lower power consumption. Advanced technologies such as free-from, curved, and transparent LCDs are adopted for a variety of new applications.
| Panel Brand | AUO |
| Panel Size | 12.1 inch |
| Panel Model | G121XN01 V0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1024(2)×768(2) , XGA |
| Display Area | 245.76(W)×184.32(H) mm |
| Outline Size | 279(W)×209(H) ×9(D) mm |
| Brightness | 500 cd/m² (Typ.) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down |
| Display Colors | 262K/16.2M 70% (CIE1931) |
| Frequency | 60Hz |
| Weight | 495g (Max.) |
| Pixel Format | RGBW Rectangle |
| Bezel Opening | 250.8(W)×189.4(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 25/10 (Typ.)(Tr/Td) |
| Lamp Type | 9S2P WLED , 50K hours , Embedded (LED Driver) |
| Touch Screen | Without |
| Application | Industrial Application |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins , Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C |
